Bamboo pallet is used most in the small and medium-sized baking-free brick machine equipment, because there are many advantages of bamboo which is reasonable price, durable, and so as to be used by most people
| Material | Bamboo |
| Density | 800kg/m3 |
| Bending Strength | ≥ 70 N/mm ² |
| Flexural Modulus | ≥4.5×10³Mpa |
| Impact Strength | ≥60 KJ/m² |
| Absorption | ≤4% |
| N/mm² | ≥ 40 |
| Surface wear | ≤0.04g/100r |
| Service life | More than 4 years |
Concrete Block Machine Bamboo Pallet is used most in small and medium-sized baking-free brick machine equipment because there are many advantages of bamboo which is reasonable price, durable, and so as to be used by most people, characteristics of bamboo Pallet below:
1). The static bending intensity of bamboo is four to five times the strength of plywood and can reduce the use quantity of the template support.
2). Bamboo pallet has a wide width and small flat-fell seam. The basic size of panel is 2.44 m * 1.22 m, which is equivalent with the area of 6.6 blocks small steel template of P3015 , with quick supporting mould and removing mould.
3).The surface of the Bamboo pallet is smooth, which is only one in eight of the steel template on the adsorption capacity of concrete, is easy to demould. The surface of concrete is smooth after demolding and can cancel the plaster operation, and shorten operation period of decoration.
4). With good resistance to water, bamboo pallet does not degum after boiling for 6 hours and remains high strength after boiling and freeze. Bibulous rate of the surface is close to steel template, and improves water retention by pouring bamboo plywood into concrete.and it is easy to maintenance in the process of concrete curing, because of deformation under the water.
5). Bamboo pallet is anti-corrosion and insect-resistant.
6). The coefficient of thermal conductivity of bamboo is 0.14-0.16 w/m.k, far smaller coefficient of thermal conductivity of steel template, and is conducive to heat preservation in winter construction.
7). With high turnover of bamboo, obvious economic benefit, the pallet can be double-sided inverted, and the used times of no-frame bamboo reaches 20-30 times.Bamboo template is very suitable for horizontal template, brick machine pallets, baking-free brick pallet, shear walls, vertical wall, viaduct, overpasses, dams, tunnels, and beam-column template, etc.
Bamboo pallet For Concrete block machine :
| block machine No. | pallets size (mm) | required quantity (piece) | Unit price (USD) |
| QT10-15 | 1300*900*30 | 1500 | |
| QT8-15 | 980*900*25 | 1200 | |
| QT6-15 | 940*830*25 | 1200 | |
| QT4-15 | 1010*550*25 | 1000 | |
| QT4-24B,QT4-25,QT4-26 | 850*550*25 | 800 | |
| QT40-1,QT40-2,QT4-28 | 850*450*25 | 600 | |
| The bamboo pallets will be produced according to clients’ requirement | |||
Bamboo pallet advantages:
1) density:800kgs/cbm, high density, strong quality
2) The bamboo pallets are made with rivets on each side, so the bamboo pallets lifespan is much longer
3) Comparing the PVC pallet, it is easy to take for workers.
